LTC4307的基本参数

制造厂商：AD
产品类别：串行总线缓冲器、扩展器和加速度计
技术类目：串行总线缓冲器、扩展器和加速度计
功能描述：Low Offset Hot Swappable 2-Wire Bus Buffer with Stuck Bus Recovery
（AD代理渠道，提供当日发货、严格的质量标准，满足您的目标价格）

LTC4307的产品详情：

The LTC4307 hot swappable, 2-wire bus buffer allows I/O card insertion into a live backplane without corruption of the data and clock busses. The LTC4307 provides bidirectional buffering, keeping the backplane and card capacitances isolated. Low offset and high VOL tolerance allows multiple devices to be cascaded on the clock and data busses. If SDAOUT or SCLOUT are low for 30ms, the LTC4307 will automatically break the bus connection. At this time the LTC4307 automatically generates up to 16 clock pulses on SCLOUT in an attempt to free the bus. A connection will resume if the stuck bus is cleared.

During insertion, the SDA and SCL lines are pre-charged to 1V to minimize bus disturbances. When driven high, the ENABLE input allows the LTC4307 to connect after a stop bit or bus idle. Driving ENABLE low breaks the connection between SDAIN and SDAOUT, SCLIN and SCLOUT. READY is an open-drain output which indicates that the backplane and card sides are connected.

应用

Live Board Insertion
Servers
Capacitance Buffer/Bus Extender
RAID Systems
ATCA

LTC4307的优势和特点：

Bidirectional Buffer with Stuck Bus Recovery
60mV Buffer Offset Independent of Load
30ms Stuck Bus Timeout
Compatible with Non-Compliant VOL I2C Devices
Prevents SDA and SCL Corruption During Live Board Insertion and Removal from Backplane
±5kV Human Body Model ESD Protection
Isolates Input SDA and SCL Line from Output
Compatible with I2CTM, I2C Fast Mode and SMBus
READY Open-Drain Output
1V Precharge on All SDA and SCL Lines
High Impedance SDA, SCL Pins for VCC = 0V
Small 8-Lead (3mm × 3mm) DFN and 8-Lead MSOP Packages

LTC4307具体的完整产品型号参数及价格（美元）：

LTC4307CDD#PBF，封装：8-Lead DFN (3mm x 3mm x 0.75mm w/ EP)，包装形式及数量：管装，121，工作温度：0 to 70C，AD官网报价：2.89（100-499个）；2.43（1000+个）

LTC4307CDD#TRPBF，封装：8-Lead DFN (3mm x 3mm x 0.75mm w/ EP)，包装形式及数量：卷带，2500，工作温度：0 to 70C，AD官网报价：2.89（100-499个）；2.43（1000+个）

LTC4307CMS8#PBF，封装：8-Lead MSOP，包装形式及数量：管装，50，工作温度：0 to 70C，AD官网报价：2.89（100-499个）；2.43（1000+个）

LTC4307CMS8#TRPBF，封装：8-Lead MSOP，包装形式及数量：卷带，2500，工作温度：0 to 70C，AD官网报价：2.89（100-499个）；2.43（1000+个）

LTC4307IDD#PBF，封装：8-Lead DFN (3mm x 3mm x 0.75mm w/ EP)，包装形式及数量：管装，121，工作温度：-40 to 85C，AD官网报价：3.44（100-499个）；2.9（1000+个）

LTC4307IDD#TRPBF，封装：8-Lead DFN (3mm x 3mm x 0.75mm w/ EP)，包装形式及数量：卷带，2500，工作温度：-40 to 85C，AD官网报价：3.44（100-499个）；2.9（1000+个）

LTC4307IMS8#3ZZPBF，封装：8-Lead MSOP，包装形式及数量：卷带，2500，工作温度：-40 to 85C，AD官网报价：

LTC4307IMS8#3ZZTRPBF，封装：8-Lead MSOP，包装形式及数量：卷带，2500，工作温度：-40 to 85C，AD官网报价：

LTC4307IMS8#PBF，封装：8-Lead MSOP，包装形式及数量：管装，50，工作温度：-40 to 85C，AD官网报价：3.44（100-499个）；2.9（1000+个）

LTC4307IMS8#TRPBF，封装：8-Lead MSOP，包装形式及数量：卷带，2500，工作温度：-40 to 85C，AD官网报价：3.44（100-499个）；2.9（1000+个）
