ADSP-2189M因超大片内存储器(1.5 MB)和低功耗(2.5v)特性而著称。

ADSP-2189M将ADSP-2100系列的基础架构（三个计算单元、数据地址生成器和一个程序序列器）与两个串行端口、一个16位内部DMA端口、一个字节DMA端口、一个可编程计时器、标志I/O和广泛的中断功能完美地结合起来。

优势

• 指令周期时间：13 ns (75 MIPS)
• 2.5 v电源，3.3 v I/O
• 32K字片内程序RAM
• 48K字片内数据存储器RAM
• 16位内部DMA端口，支持高速访问片内存储器
• 8位DMA字节存储器端口，支持程序和数据存储器透明传递

• 0.4 mA/MIPS
• 字节存储器接口用于存储数据表和程序覆盖
• 可编程存储器选通和独立的I/O存储器空间可实现“无缝”系统
• 兼容ADSP-2100系列代码和函数
• 100引脚LQFP封装
• 144引脚小型BGA封装

ADSP-2189MBSTZ-266，封装：100-Lead LQFP (14mm x 14mm)，包装形式及数量：托盘，90，工作温度：-40 to 85C，AD官网报价：

ADSP-2189MKCA-300，封装：144-Ball CSPBGA (10mm x 10mm x 1.4mm)，包装形式及数量：托盘，184，工作温度：，AD官网报价：

ADSP-2189MKSTZ-300，封装：100-Lead LQFP (14mm x 14mm)，包装形式及数量：托盘，90，工作温度：0 to 70C，AD官网报价：

EVAL-2189-EZKIT：EZ-KIT Lite Evaluation Kit for ADSP-218x Processor

The ADSP-2189M EZ-KIT Lite provides developers with a cost-effective method for initial evaluation of the powerful ADSP-218x DSP family architecture. The ADSP-2189M EZ-KIT Lite includes a stand-alone ADSP-2189M DSP board and fundamental code generation debug software. With this EZ-KIT Lite, users can learn about DSP hardware and software development and evaluate potential applications of the ADSP-218X M family of DSPs. The ADSP-2189M EZ-KIT Lite provides an evaluation suite of the VisualDSP++ development environment with the C compiler, assembler, and linker. All software tools are limited to use with the EZ-KIT Lite product.

Demonstration programs shipped with this EZ-KIT Lite system include common signal processing algorithms such as convolution and Fibonacci calculations. Programs that demonstrate the use of the hardware features of the ADSP-2189M are provided including interrupts, overlays, timers and the on-board codec.

Part Number
ADZS-2189M-EZLITE
