The AD9912 is a direct digital synthesizer (DDS) that features an integrated 14-bit digital-to-analog converter (DAC). The AD9912 features a 48-bit frequency tuning word (FTW) that can synthesize frequencies in step sizes no larger than 4 μHz. Absolute frequency accuracy can be achieved by adjusting the DAC system clock.

The AD9912 also features an integrated system clock phase-locked loop (PLL) that allows for system clock inputs as low as 25 MHz.

The AD9912 operates over an industrial temperature range, spanning ?40°C to +85°C.

Applications

• Agile LO frequency synthesis
• Low jitter, fine tune clock generation
• Test and measurement equipment
• Wireless base stations and controllers
• Secure communications
• Fast frequency hopping

• 1 GSPS internal clock speed (up to 400 MHz output directly)
• Integrated 1 GSPS 14-bit DAC
• 48-bit frequency tuning word with 4 μHz resolution
• Differential HSTL comparator
• Flexible system clock input accepts either crystal or external reference clock
• On-chip low noise PLL REFCLK multiplier
• 2 SpurKiller channels
• See data sheet for additional information.

AD9912ABCPZ，封装：64-Lead LFCSP (9mm x 9mm w/ EP)，包装形式及数量：托盘，260，工作温度：-40 to 85C，AD官网报价：54.82（100-499个）；46.6（1000+个）

AD9912ABCPZ-REEL7，封装：64-Lead LFCSP (9mm x 9mm w/ EP)，包装形式及数量：卷带，750，工作温度：-40 to 85C，AD官网报价：54.82（100-499个）；46.6（1000+个）

AD9912BCPZ-REEL7，封装：64-Lead LFCSP (9mm x 9mm w/ EP)，包装形式及数量：卷带，750，工作温度：，AD官网报价：

EVAL-AD9912：AD9912 评估板

本页面提供有关评估AD9912的评估板文档和订购信息。
