AD8079的基本参数

制造厂商：AD
产品类别：视频放大器和模拟视频功能
技术类目：低噪声运算放大器(≤ 10nV/√Hz)
功能描述：Dual 260 MHz Gain = +2.0 & +2.2 Buffer
（AD代理渠道，提供当日发货、严格的质量标准，满足您的目标价格）

AD8079的产品详情：

The AD8079 is a dual, low power, high speed buffer designed to operate on ±5 V supplies. The AD8079's pinout offers excellent input and output isolation compared to the traditional dual amplifier pin configuration. With two ac ground pins separating both the inputs and outputs, the AD8079 achieves very low crosstalk of less than -70 dB at 5 MHz.

Additionally, the AD8079 contains gain setting resistors factory set at G = +2.0 (A grade) or Gain = +2.2 (B grade) allowing circuit configurations with minimal external components. The B grade gain of +2.2 compensates for gain loss through a system by providing a single-point trim. Using active laser trimming of these resistors, the AD8079 guarantees tight control of gain and channel-channel gain matching. With its performance and figuration, the AD8079 is well suited for driving differential cables and transformers. Its low distortion and fast settling are ideal for buffering high speed dual or differential A-to-D converters.

The AD8079 features a unique transimpedance linearization circuitry. This allows it to drive video loads with excellent differential gain and phase performance of 0.01% and 0.02° on only 50 mW of power per amplifier. It features gain flatness of 0.1 dB to 50 MHz. This makes the AD8079 ideal for professional video electronics such as cameras and video switchers.

The AD8079 offers low power of 5 mA/amplifier (VS = ±5 V) and can run on a single +12 V power supply while delivering over 70 mA of load current. All of this is offered in a small 8-pin SOIC package. These features make this amplifier ideal for portable and battery powered applications where size and power are critical.

The outstanding bandwidth of 260 MHz along with 800 V/μs of slew rate make the AD8079 useful in many general purpose high speed applications where dual power supplies of ±3 V to ±6 V are required.

The AD8079 is available in the industrial temperature range of -40°C to +85°C.

AD8079的优势和特点：

Factory Set Gain
Gain of 2.2 Compensates for System Gain Loss
Minimizes External Components
Tight Control of Gain and Gain Matching (0.1%)
Optimum Dual Pinout
Simplifies PCB Layout
Low Crosstalk of -70dB @ 5MHz
Excellent Video Specifications (RL=150 ?)
Gain Flatness 0.1dB to 50MHz
0.01% Differential Gain Error
0.02° Differential Phase Error

Low Power of 50 mW/Amplifier (5mA)
High Speed and Fast Settling
260MHz, -3dB Bandwidth
750 V/μs Slew Rate (2 V Step), 800 V/μs 4 V Step)
40 ns Settling Time to 0.1% (2V Step)
Low Distortion of -65dBc THD, fc=5MHz
High Output Drive of Over 70mA

AD8079具体的完整产品型号参数及价格（美元）：

AD8079ARZ，封装：8-Lead SOIC，包装形式及数量：管装，98，工作温度：-40 to 85C，AD官网报价：5.81（100-499个）；5.24（1000+个）

AD8079ARZ-REEL，封装：8-Lead SOIC，包装形式及数量：卷带，2500，工作温度：-40 to 85C，AD官网报价：5.81（100-499个）；5.24（1000+个）

AD8079ARZ-REEL7，封装：8-Lead SOIC，包装形式及数量：卷带，1000，工作温度：-40 to 85C，AD官网报价：5.81（100-499个）；5.24（1000+个）

AD8079BRZ，封装：8-Lead SOIC，包装形式及数量：管装，98，工作温度：-40 to 85C，AD官网报价：7.56（100-499个）；6.82（1000+个）

AD8079BRZ-REEL，封装：8-Lead SOIC，包装形式及数量：卷带，2500，工作温度：-40 to 85C，AD官网报价：7.56（100-499个）；6.82（1000+个）

AD8079BRZ-REEL7，封装：8-Lead SOIC，包装形式及数量：卷带，1000，工作温度：-40 to 85C，AD官网报价：7.56（100-499个）；6.82（1000+个）
